ADVENTURE WAITS AT THE NEXT CORNER

Beauty is more than skin deep: the Aim's sleek looks are thanks to its Smooth Welded head tube and seat tube junctions. It incorporates a threaded bottom bracket and internal cable routing for long-lasting service and simple maintenance. There's even a flat disc mount that integrates seamlessly with our kickstand mount, and integrated mounting points for ACID mudguards and carrier. Updated geometry includes a lower top tube for more confident handling, and there's plenty of room to run wide, grippy and comfortable 2.25in tyres. Our SizeSplit system has an expanded range, too, so however tall you are there'll be an Aim that fits perfectly.

WHERE D'YOU WANT TO GO TODAY? WITH THE AIM PRO'S COMFORTABLE SUSPENSION FORK, GRIPPY TYRES AND STRONG HYDRAULIC DISC BRAKES, THE CHOICE IS YOURS. TAKE THE ROAD LESS TRAVELLED, AND SEE WHERE IT LEADS YOU...

Got an off-road itch that needs scratching? The Aim Pro could be the relief you're looking for. With its grippy tyres and 100mm suspension fork, it's got the comfort and control you'll need to keep riding when you reach the end of the road. Wide-ratio Shimano 2x8 gears will help you see off the steepest climbs, and strong hydraulic brakes put you in control on the descents. Best of all, SizeSplit makes it easy to find the perfect fit for every rider – and the frame is even ready to accept a future dropper post upgrade.

FRAME

·         FRAME

Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount

·         SIZE

Size Split: 27.5: XS (14"), S (16") // 29: M (18"), L (20"), XL (22"), XXL (24")

SUSPENSION

·         SUSPENSION FORK

SR Suntour XCT Disc, 100mm

DRIVETRAIN & BRAKES

·         BRAKE SYSTEM

Tektro HD-M275 / TKD-150, Hydr. Disc Brake (160/160)

·         REAR DERAILLEUR

Shimano RD-M3020, 8-Speed

·         FRONT DERAILLEUR

Shimano FD-M315, Top Swing, 31.8mm Clamp

·         SHIFTERS

Shimano SL-M315, Rapidfire-Plus

·         BOTTOM BRACKET

Feimin FP-B902N, 73mm BSA

·         CRANKSET

Shimano FC-M315, 36x22T, 170mm

·         CASSETTE

Shimano CS-HG31, 11-34T

·         CHAIN

KMC Z8.3

COCKPIT

·         HANDLEBAR

CUBE Rise Trail Bar, 680mm

·         STEM

CUBE Performance Stem Pro, 31.8mm

·         GRIPS

ACID React

·         HEADSET

CUBE FPH868, Semi-Integrated

WHEELS

·         FRONT HUB

CUBE Alloy Light, QR, 6-Bolt

·         REAR HUB

CUBE Alloy Light, QR, 6-Bolt

·         RIMS

CUBE ZX20, 32H, Disc

·         TYRES

CUBE IMPAC Smartpac, 2.25

FINISHING KIT

·         SEAT POST

CUBE Performance Post, 27.2mm

·         SADDLE

Natural Fit Venec Lite

·         PEDALS

CUBE PP MTB

PRODUCT INFORMATION

·         WEIGHT

14,7 kg

·         COLOUR

grey´n´flashyellow
